Unknowns, Non-Ferrous - Set 2 -
Fifth specimen - M.I.T.'s # 43
|
This is an aluminum - silicon alloy.
My first photomicrograph was made at 50X; the second was made at
500X. The color balance is a little too green in the first one
and a little too blue in the second.
|
|
See if you can work out where this alloy is in the aluminum
- silicon phase diagram and what sort of metallurgical treatment it
either did or didn't have.
Hint: Was it inoculated ?
Write out your answer; complete all or
part of the set; and
then apply
for a
Username & Password so you can activate the link at the bottom of this page.
|
